In this, you will learn how to find the roots of equations using Secant Method in Python Programming.
Secant Method
The second method is used to find the origin of the equation
F (x) = 0. It starts from two different estimates, x1 and x2 for the root. It is a repetition process with linear interpolation to a source.
The iteration stops if the difference between the two intermediate values is less than the convergence factor.
Steps:
1. x1, x2, E, n // E = convergence indicator
2. Calculate f (x1), f (x2)
3. if (f (x1) * f (x2) = E); // Repeat the loop until convergence
4. Print the value of 'x0' // value of the root
5. Print the 'n' // iterations
5. Print the 'n' // iterations
else
6. Print "Source not found"
6. Print "Source not found"
In this Python program, x0 & x1 are the two initial estimation values, e is the tolerable error and f (x) is the actual non-linear function whose root is obtained using the second method. Variable x2 has approximately root in each step.
Example 1: Program to find the solution of equation x2-9 using secant method
Python Code:
from pylab import *
def secant(f,x0,x1,eps):
f_x0=f(x0)
f_x1=f(x1)
iteration_counter=0
while abs(f_x1)>eps and iteration_counter<100:
try:
x2 = float(f_x1-f_x0)/(x1-x0)
x = x1-float(f_x1)/x2
except:
print("error")
x0 = x1
x1 = x
f_x0=f_x1
f_x1=f(x1)
iteration_counter+=1
if abs(f_x1)>eps:
iteration_counter-=1
return x, iteration_counter
def f(x):
return x**2-9
x0 = 10
x1 = x0 - 1
solution, no_iterations=secant(f,x0,x1,eps=0.00001)
if no_iterations>0:
print("number of function call: %d" %(2+no_iterations))
print("solution is:", solution)
else:
print("solution is not found")
Output:
number of function call: 9
solution is: 3.000000000915234
Example 2: Program to find the solution of equation x3-4 using secant method
Python Code:
from pylab import *
def secant(f,x0,x1,eps):
f_x0=f(x0)
f_x1=f(x1)
iteration_counter=0
while abs(f_x1)>eps and iteration_counter<100:
try:
x2 = float(f_x1-f_x0)/(x1-x0)
x = x1-float(f_x1)/x2
except:
print("error")
x0 = x1
x1 = x
f_x0=f_x1
f_x1=f(x1)
iteration_counter+=1
if abs(f_x1)>eps:
iteration_counter-=1
return x, iteration_counter
def f(x):
return x**3-4
x0 = 10
x1 = x0 - 1
solution, no_iterations=secant(f,x0,x1,eps=0.00001)
if no_iterations>0:
print("number of function call: %d" %(2+no_iterations))
print("solution is:", solution)
else:
print("solution is not found")
Output:
number of function call: 13
solution is: 1.5874010554986935
